Introduction

Ankylosing spondylitis (AS) is a systemic, multifactorial, chronic rheumatic disease that affects the joints of the axial skeleton (1). A thorough physical examination, in conjunction with family history analysis, consideration of the patient's individual medical history, X-ray imaging and serum human leukocyte antigen (HLA)-B27 testing, is required for an accurate diagnosis (2). Previous research has indicated that the incidence of spontaneous pneumothorax in patients with AS is 0.29%, higher than that observed in the general population (1).

Although the underlying etiology of spontaneous pneumothorax remains unknown, it is an uncommon lung disease that disrupts respiration in otherwise healthy men who tend to be tall and thin (3). Spontaneous pneumothorax results from the rupture of a subpleural emphysematous bleb typically located at the apex of the lung, leading to the accumulation of air in the pleural cavity (3). During the course of diagnosis and treatment, X-ray imaging is often utilized in patients with spontaneous pneumothorax (4).

Chronic myeloid leukemia (CML) is characterized by the abnormal growth of mature myeloid cells; it has been associated with translocation involving chromosomes 9 and 22, resulting in the formation of the Philadelphia chromosome (5,6). The cause of this translocation is unknown, although exposure to ionizing radiation is likely to be a risk factor (7). Previous studies have demonstrated a dose-dependent risk of CML in patients with cancer who undergo radiation therapy (8,9) and experience repeated exposure to diagnostic radiography (7).

Our previous report described the case of a patient with AS who was diagnosed with CML following repeated chest radiography and computed tomography (CT) (10); the report focused primarily on a possible association between low-dose X-ray-derived radiation exposure and CML. However, a recent follow-up revealed that this patient experienced mild lower back pain as well as spontaneous pneumothorax during the course of the disease. No prior reports described the simultaneous occurrence of spontaneous pneumothorax and AS followed by CML after diagnostic exposure to low-dose X-rays. Thus, it was surmised that it was important to reanalyze this previous case (10), and to investigate the possible associations between spontaneous pneumothorax and AS, and CML. The present study reviews the unusual presence of CML following repeated diagnostic low-dose X-ray exposure in a patient with recurrent pneumothorax and AS.

Case report

Our previous report (10) described a case of recurrent spontaneous pneumothorax and the development of CML following repeated exposure to low-dose diagnostic chest radiography and CT. The findings indicated the importance of investigating the potential dangers of low-dose diagnostic radiation. However, that report only included follow-up information up to January 2015 (10). A more recent follow-up revealed that the patient was diagnosed with AS one month later. As the simultaneous occurrence of these two conditions is quite rare, it was considered vital to reanalyze the case.

The patient was a slender man with no history of smoking who had been diagnosed at the Department of Respiratory Medicine, Zhejiang Provincial Hospital of Traditional Chinese Medicine (Hangzhou, China) with spontaneous pneumothorax on May 6, 2013 at the age of 26. Following the insertion and removal of chest tubing, the patient was discharged from hospital. However, the patient then developed recurrent pneumothorax. On May 24, 2013, the patient underwent thoracoscopic surgery for the resection of bullae. Over the 9 months following the initial diagnosis of spontaneous pneumothorax, the patient underwent 10 radiographic examinations and 4 CT scans of the chest, constituting a total effective radiation dose of 11.7 mSv. On April 18, 2014 a general health examination revealed that the patient's white blood cell (WBC) count had increased to 13.9×109/l (normal range, 4–10×109/l). On June 6, 2014, the patient's WBC count had increased to 25.4×109/l. Following bone marrow smear testing on June 13 2014 and a karyotype analysis on June 19, 2014 the patient was diagnosed with CML (10).

On June 28, 2014, the patient began receiving imatinib mesylate at a dose of 400 mg/day for the treatment of CML. A WBC count revealed that the abnormally high WBC count had begun to decrease on September 4, 2014. An additional karyotype analysis was subsequently performed (Table I) and a second bone marrow smear test on May 5, 2015 revealed no abnormal cells.

Table I. Karyotype analysis of the patient.

Table I.

Karyotype analysis of the patient.

Date	BCR/ABL1a (p210)	BCR/ABL1 (copy)	ABL1 (copy)	BCR-ABL1/ABL1	IS BCR-ABL1/ABL1
Jun 19 2014	+	−(P230)	−	−	−
Feb 13 2015	+	61.26	1.79×104	0.003	0.003
Jun 25 2015	−	−	1.63×104	0	0
Oct 19 2015	−	−	3.26×104	0	0

a BCR-ABL1 is an oncogenic protein resulting from fusion of the tyrosine kinase ABL1 with the BCR protein. BCR, breakpoint cluster region; ABL1, Abelson-1; IS, international standard.

The patient continued to receive imatinib mesylate until June 2016. As of January 2015 he had reported no feelings of discomfort, as previously described (10). However, the patient did report bilateral sacroiliac joint pain in February 2015. Careful inquiry revealed that the patient had begun to feel intermittent, mild bilateral sacroiliac joint pain as early as January 2014, 6 months prior to the initiation of imatinib treatment. However, the patient had not noted this information because symptoms were mild.

Although the risk of developing CML following repeated exposure to chest radiography and CT was of concern, a pelvic CT scan was ultimately performed on February 16, 2015 to confirm the diagnosis of AS (Fig. 1). The scan revealed bilateral narrowing of the sacroiliac joints in addition to bilateral cystic changes, which were more apparent at the surface of the left sacroiliac joint.

Figure 1. Computed tomography image of the narrowing of the gap in the bilateral sacroiliac joint, and cystic changes in the bilateral iliac bones. The grey arrow indicates narrowing of the sacroiliac joint on the left. Cystic changes and damage were more apparent at the surface of the left sacroiliac joint (black arrows).

Joint pain, muscle pain and muscle cramps are known potential side effects of imatinib. In the current case, the location and nature of the pain had not changed after receiving imatinib for 6 months. Moreover, a pelvic CT scan was performed 7 months after the initiation of imatinib treatment. To the best of our knowledge, there have been no prior reports of imatinib resulting in AS, thus we hypothesize that AS occurred before the patient was administered imatinib.

The patient tested negative for HLA-B27 and rheumatoid factor, but a diagnosis of AS was reached in accordance with the New York criteria (11). The occurrence of pneumothorax and the subsequent occurrence of CML and AS were documented within the same 2-year period. The Institutional Ethics Committee of the Zhejiang Provincial Hospital of Traditional Chinese Medicine (Hangzhou, China) approved the current study. The subject of this case report provided written informed consent agreeing to publication.

Discussion

The present study describes the case of a 29-year-old man who presented with recurrent spontaneous pneumothorax, then AS, and who subsequently developed CML following repeated exposure to low-dose diagnostic X-ray radiation. To the best of our knowledge, these combined medical conditions have not been previously reported in the clinical literature.

The patient visited the physician due to pneumothorax; initially, only chest CT scans and chest X-ray data were available. Pelvic CT scanning was not conducted until February 16th, 2015, when it was performed to confirm the diagnosis of AS (Fig. 1). That scan revealed the bilateral narrowing of the sacroiliac joints, in addition to bilateral cystic changes, which were more apparent at the surface of the left sacroiliac joint. The possibility that imatinib caused the occurrence of AS was rejected for the following reasons. Firstly, neither the location nor the nature of the pain changed; secondly, following commencement of imatinib treatment there were no evident changes in the patient's symptoms: Thirdly, the pelvic CT scan was performed just 7 months after the initiation of imatinib treatment; lastly, as no reports of imatinib-induced AS could be located in the literature, we considered this eventuality to be unlikely.

In the majority of cases of unclear etiology, spontaneous pneumothorax is reported in healthy young men and stems from the rupture of apical blebs on the visceral pleura (3). Lee et al (1) reported that the incidence of spontaneous pneumothorax in patients with AS is 0.29% (n=1,028), higher than that reported for the general population. Although rare, the development of apical pulmonary fibrosis and bullous disease has been recognized as an extra-articular manifestation of AS (12). Studies have also demonstrated that recurrent pneumothorax may be caused by the inadequate sealing of air leaks, and that this can be responsible for the persistence of pneumothorax in patients with connective tissue autoimmune diseases, including AS (1,13).

In prior reports involving AS and concurrent pneumothorax, the pneumothorax was diagnosed a number of years (4–30 years) following the diagnosis of AS (1,14,15). In one previously reported case study, the pneumothorax was diagnosed 16 months after radiation exposure (16). However, the current patient presented with recurrent spontaneous pneumothorax prior to a diagnosis of AS. Notably, previous studies have indicated that the incidence of occult pneumothorax may be underestimated in patients with AS, owing to the vague nature of the symptoms or lack of diagnosis (1,12). Thus, patients with recurrent spontaneous pneumothorax should be thoroughly evaluated for AS.

Specific studies have suggested that rheumatic diseases may develop during the course of CML, although it remains unclear whether the development of rheumatic disease in patients with CML is due to the long-term use of drugs or the underlying disease (17,18). AS is unlikely to be caused by drugs; however, it is imperative to bear in mind that AS, an autoimmune and inflammatory disease, may impair immune function and render patients susceptible to diseases stemming from gene mutations (19). A previous study described a case of CML in a patient with AS following multiple CT imaging sessions (20). Although few reports have documented an association between AS and the development of CML following exposure to low-dose radiation, studies indicate that the risk of hematopoietic cancer is increased in patients with AS (21). The aforementioned findings, together with those of the current case report, indicate that patients with AS may be susceptible to the development of CML following low doses of radiation compared with healthy individuals.

Although blood tests for HLA-B27 are positive in >90% of Chinese patients with AS (22), the present patient tested negative for HLA-B27. Numerous studies have also failed to detect an association between HLA-B27 in AS and spontaneous pneumothorax (1,12,14,15). Thus, whether patients with AS who test negative for HLA-B27 are more sensitive to X-ray damage remains to be elucidated. In addition, the potential contributions of sex, age and smoking history to the development of pneumothorax have been reported (1,12,14,15). Therefore, the evidence accumulated to date indicates that further research into the association between spontaneous pneumothorax and sensitivity to radiation in patients with AS and CML is required.

Acknowledgements

The authors would like to thank the National Natural Science Foundation of China, Beijing, China for supporting the present study (grant no. 81400107).
