Introduction

Adult onset Still's disease (AOSD) is a rare multi-systemic inflammatory disease of unknown etiology and pathogenesis, which predominantly affects young adults, and most commonly occurs before the age of 35 years old (1–4). Its main features are high spiking fever, evanescent rash, lymphadenopathy, hepatosplenomegaly, leukocytosis, elevated liver enzymes, erythrocyte sedimentation rate, and serum ferritin. However, due to non-specific clinical performance, laboratory and imaging examinations, the diagnosis of AOSD first requires the exclusion of other diseases including infectious, inflammatory and malignant diseases (5–7). Thus, it is important to rule out a wide range of other diseases, including malignant, infectious and rheumatic diseases before the definite diagnosis of AOSD (2,6,8).

Numerous clinical studies have demonstrated that the important roles of 18F-fluorodeoxyglucose positron emission tomography/computed tomography (18F-FDG PET/CT) examinations in obtaining differential diagnoses of malignant vs. benign diseases. In addition, 18F-FDG PET/CT scanning is more effective in evaluating the involved extent of the disease. At present, the majority of knowledge concerning 18F-FDG PET/CT imaging in patients with AOSD is limited to sporadic case reports (2,9–15) and few previous studies (16,17). Thus, the purpose of the present study was to summarize the imaging characteristics of 18F-FDG PET/CT and evaluate the potential efficacy of using PET/CT in patients with AOSD.

Materials and methods

Patients

Between November 2010 and March 2015, 32 patients with definite AOSD were enrolled from Zhongshan Hospital (Shanghai, China) to this retrospective analysis based on the criteria of Yamaguchi et al (18). It contains 4 major (fever, rash, arthritis and leukocytosis) and 5 minor (sore throat, lymphadenopathy, hepatomegaly/splenomegaly, altered liver function test and negative for antinuclear antibodies and rheumatoid arthritis) criteria. A total of 5 or more criteria with at least 2 major criteria are required to make the diagnosis. All procedures performed involving human participants were in accordance with the ethical standards of the Institutional Review Board of Zhongshan Hospital, Fudan University, and with the 1964 Helsinki Declaration and its later amendments or comparable ethical standards. The present study was approved by the Ethics Committee of Zhongshan Hospital, Fudan University (Shanghai, China) and informed consent was obtained from all individual participants included in the study.

18F-FDG PET/CT scan

18F-FDG PET/CT scanning was performed on a Discovery VCT 64 System (GE Healthcare Biosciences, Milwaukee, WI, USA) with a 15.7 cm axial field view. Patients were required to fast for a minimum of 6 h prior to imaging, and serum glucose levels were maintained under 7.4 mmol/l. PET/CT images were obtained approximately 60 min subsequent to intravenous administration of 3.7–5.6 MBq of 18F-FDG per kilogram of body weight. A total of 6 or 7 bed positions (dependent on the patient's height) from the vertex of skull to middle of the thighs were imaged. PET images were acquired for 2.5 min per bed position. CT was performed on the same scanner without contrast administration. The CT scan data were collected with 140 kV, 200 mAs (adjusted by auto mA) and a gantry rotation speed of 0.8 sec. All CT scans were obtained using 3.75-mm-thick axial slices. Integrated PET and CT images were obtained automatically on Xeleris (GE Healthcare Biosciences) or Advantage workstations (GE Healthcare Biosciences).

Visual and semi-quantitative analysis

PET/CT results were analyzed and interpreted by two experienced Nuclear Medicine physicians who were blind to the patients' clinical information, other conventional imaging findings and the pathology results. Increased 18F-FDG uptake by spleen and/or bone marrow was defined as that was greater than liver. This method has been previously used to evaluate spleen and bone marrow uptake in lymphoma and leukemia (19,20). In cases of discrepancy regarding PET/CT results, a consensus was reached after mutual discussion between two physicians. Areas of focally increased accumulation known to represent physiological 18F-FDG uptake, such as brown fat, were excluded. For semi-quantitative analysis, the maximal standardized uptake value (SUVmax) was analyzed as published previously (21). SUVmax was calculated as decay-corrected maximum activity concentration in the lesion divided by administered activity divided by body weight in kilograms. The SUVmax of a region of interest located in the right lobe of the liver served as the reference. Associated results, including splenomegaly, lymph node swelling and other lesions, were additionally evaluated. In cases of multiple lymph nodes, SUVmax was calculated for all lesions, and the highest SUVmax was selected.

Pathology

Pathological examinations were performed: 26 cases on bone marrow, and 9 cases on lymph node biopsies. The pathology was reviewed by 2 experienced board-certified pathologists and all cases were clinically monitored a minimum of 1 year.

Statistical analysis

All data are expressed as the means and standard deviations. Statistical analysis was performed using Student's t-test using SPSS software, version 18.0 (SPSS Inc., Chicago, IL, USA). P<0.05 was considered to indicate a statistically significant difference.

Results

Clinical data

A total of 32 patients with AOSD, comprising 25 female and 7 male patients with an average age of 39±15 years (range, 19–80 years) took part in the present study. The patients were admitted to the hospital with various non-specific clinical features, including fever, rash, joint pain, sore throat, fatigue, skin itching, and lymphadenopathy. Fever (32/32, 100.0%) with the range of the maximum temperature (Tmax) from 39–41°C, rash (18/32, 56.3%) and joint pain (16/32, 50.0%) were the top three clinical symptoms.

18F-FDG PET/CT imaging

As presented in Table I, among 32 patients, no normal case was observed. Diffusely abnormal FDG accumulation by the spleen and bone marrow was the main observation on PET/CT images, followed by lymphadenopathy with abnormal FDG uptake. A total of 27 cases out of the 32 patients were identified with diffusely elevated FDG uptake by the spleen, and the average SUVmax was 4.2±1.1 (range, 2.5–6.7), and 19 of 27 cases exhibited swelling of the spleen. The remaining 5 cases were without abnormal FDG uptake, and only two patients were identified to present with marginal spleen swelling. The mean SUVmax of these 5 spleens was 2.1±0.6 (range, 1.5–2.8), which was significantly lower than that of 27 cases (P<0.05).

Table I. Imaging characteristics of 32 patients with adult onset Still's disease demonstrated with 18F-FDG PET/CT.

Table I.

Imaging characteristics of 32 patients with adult onset Still's disease demonstrated with 18F-FDG PET/CT.

Organs and tissues	Positive cases	Negative cases
Spleen	27	5
SUVmax range	2.5–6.7	1.5–2.8
Mean ± standard deviation	4.2±1.1a	2.1±0.6a
Bone marrow	26	6
SUVmax range	2.8–7.0	1.3–3.4
Mean ± standard deviation	4.6±0.6a	2.6±0.7a
Lymph nodes	20	5
SUVmax range	2.2–13.9	–
Mean ± standard deviation	5.9±3.1	–
Skin	1	31
Joint	1	31
Serous effusion	7	25

a P<0.05.

In addition, 26 of 32 patients presented with diffuse and homogeneous glucose accumulation by bone marrow of whole body, with the mean SUVmax of 4.6±0.6 (range, 2.8–7.0). The remaining 6 cases were observed without FDG uptake, and the mean SUVmax was 2.6±0.7 (range, 1.3–3.4). There was significant difference between the abovementioned two groups (P<0.05).

Among 32 cases, 20 patients were identified with lymphadenopathy with positive FDG uptake on PET/CT images. The performance of FDG metabolism by lymph nodes was mixed, with an SUVmax range from 2.2–13.9, and the mean SUVmax was 5.9±3.1. The range of maximum diameter of lymph nodes was from 9.3–24.2 mm, and the mean diameter was 15.3–4.2 mm. The lymph node swelling in 2 cases was limited to local lymph nodes (one in mediastinum, the other in bilateral necks), and the remaining 18 cases displayed varied lymph node involvement (neck, clavicle, axillary, mediastinum, lung hilar, abdominal, retroperitoneal, pelvic and inguinal regions). The most involved lymph nodes were located in the neck (19/32) and chest (18/32), the abdomen and pelvic regions were secondary (13/32).

In addition, 1 case presented with marginally increased FDG uptake by the skin of the neck, shoulders and chest, which was caused by the skin rash of the corresponding part (Fig. 1). Another case displayed elevated FDG activity in the right shoulder joint, but the patient had no history of joint diseases. A total of 7 cases presented with effusion on the PET/CT images, including 4 cases with diffuse effusion (pleural, pericardial, abdominal and pelvic effusion; Fig. 2) and 3 cases with local effusion (2 patients with pericardial effusion and 1 patient with pelvic effusion). However, in the present study, no case of liver swelling and/or abnormal glucose metabolism was observed, and the mean SUVmax of the liver was 2.5±0.5 (range, 1.7–3.5).

Figure 1. A 36-year-old female patient presented with intermittent fever (Tmax of 39.6°C) and rash for almost 1 year. AOSD was diagnosed 10 months ago, and the patient received the therapy of CSs. The rash was worsened after the reduction of CSs, and was widely located in the skin of trunk and limbs. 18F-FDG PET/CT images are presented: (A) MIP, (B) PET, (C) CT, (D) PET/CT, (E) PET, (F) CT, (G) PET/CT. These images indicated diffusely increased FDG uptake by the skin of the neck, shoulders and chest (arrows), with an SUVmax of 3.1. In addition, marginal swelling of the spleen was observed with diffuse FDG uptake. Lymph nodes of the left cervical, bilateral axillary (triangle arrows), lung hilar and abdominal regions were enlarged with mildly increased radioactivity, of which the SUVmax was 2.2. AOSD, adult onset Still's disease; CSs, corticosteroids; 18F-FDG, fluorodeoxyglucose; PET, positron emission tomography; CT, computerized tomography; MIP, maximum intensity projection; SUV, standardized uptake value.

Figure 2. A 57-year-old male patient presented with fever (Tmax of 39.0°C) for 3 weeks, which was not relieved by anti-inflammatory therapy. 18F-FDG PET/CT imaging indicated that in addition to diffuse FDG uptake by the spleen and bone marrow (A: MIP, black arrows), bilateral pleural effusion with partial atelectasis was observed (B-D: PET, CT and PET/CT, white arrows). 18F-FDG, fluorodeoxyglucose; PET, positron emission tomography; CT, computerized tomography; MIP, maximum intensity projection.

Pathology and clinical follow-up

Among 32 patients, 26 cases underwent bone marrow biopsy: 9 cases displayed normal bone marrow biopsies, 15 cases showed the non-specific reactive hyperplasia of hematopoietic cells, 1 case presented with non-specific low bone marrow hyperplasia, and 1 case with non-specific increased granulocyte ratio. Lymph node biopsies were conducted in 9 patients out of 32, and the results demonstrated non-specific inflammation in 8 cases, and a normal result in 1 case. With the exception of 1 case, the remaining 31 patients responded well to corticosteroids (CSs) and the symptoms were markedly improved. The symptom of this case returned, and was finally improved under the control of methotrexate and methylprednisolone.

Discussion

AOSD is a chronic systemic inflammatory disease, first described by Bywaters in 1971 (10,22). Due to the non-specific features in clinical performance, laboratory tests and imaging modalities, AOSD remains difficult to diagnose. In the present study, all 32 patients were admitted to the hospital based on fever of unknown origin. In order to exclude malignancy, 18F-FDG PET/CT scans were performed, and the imaging characteristics of AOSD on PET/CT imaging were summarized and analyzed.

Previous studies have indicated that the results of 18F-FDG PET/CT for AOSD are mixed. Funauchi et al (10) presented a case of AOSD with increased FDG activity in the liver and spleen alone. Roy et al (9) reported elevated FDG level in the joints of whole body associated with AOSD in a 28-year-old patient. In another case reported by de Graaff et al (14), increased FDG accumulation by the carotids, the wrist and the large vessels of the legs was demonstrated. Yamashita et al (17) reported that in 7 cases with AOSD, FDG uptake was additionally positive in the pericardium, pleura, salivary glands, eyelids and muscles. Other cases reported increased FDG uptake was identified in multiple lymph nodes across the whole body (2,12,16,17), which could not lead to differential diagnosis with malignant lymphoma. In agreement with previous studies, the 18F-FDG PET/CT images in patients with AOSD presented with varied results. Increased FDG activity in the spleen (84.4%), bone marrow (81.3%) and lymphadenopathy (62.5%) were the most common observations. In addition, 21.9% of patients were exhibited with effusion without FDG uptake, and another 2 cases showed abnormal FDG uptake by the skin and joint, respectively. Notably, no elevated FDG uptake in the liver and vessels were observed in the present study.

Based on the imaging features of this study, the roles of 18F-FDG PET/CT in AOSD were retrospectively investigated. Firstly, 18F-FDG PET/CT could display both anatomic and functional changes of AOSD, and evaluated the involved extent of AOSD. For example, as presented in Fig. 3, the case only displayed diffusely elevated FDG activity in bone marrow of whole body on PET/CT images. The case in Fig. 4 demonstrated that although multiple enlarged lymph nodes of the whole body with mildly increased radioactivity were displayed on PET/CT images, the benign diseases of lymph nodes such as inflammation rather than malignancies were diagnosed based on the size, morphology, density, and SUVmax of the lymph nodes in this case. However, for other cases, as presented in Figs. 5 and 6, which was difficult to make differential diagnosis with lymphoma. Secondly, it could guide the biopsy of tissues with abnormal FDG accumulation including lymph nodes, bone marrow, skin and other tissues. Regarding the cases in Figs. 5 and 6, the biopsies of the lymph nodes were performed under the guide of 18F-FDG PET/CT imaging, which contributed to suggest the proper lymph node applied for the biopsy. Finally, 18F-FDG PET/CT is helpful in the post-treatment evaluation of AOSD. Although these data weren't investigated in the present study, Choe et al (2) and Yamashita et al (17) identified significant improvements (decreased SUV level) in the initially abnormally sized radioactive lesions in the follow-up images of PET/CT.

Figure 3. A 28-year-old male patient presented with fever (Tmax of 41.1°C) and joint pain for 1 month. 18F-FDG PET/CT imaging indicated only diffuse increases in FDG accumulation by bone marrow (A: MIP, arrows), of which the SUVmax was 2.8. In addition, marginal spleen swelling without abnormal FDG uptake was also observed (B-D: PET, CT and PET/CT). 18F-FDG, fluorodeoxyglucose; PET, positron emission tomography; CT, computerized tomography; MIP, maximum intensity projection; SUV, standardized uptake value.

Figure 4. A 28-year-old female presented with intermittent fever, bilateral knee joints pain, and rash for 1 month, and Tmax was 40.4°C. The treatment of antibiotics was invalid, and local CT displayed multiple enlarged lymph nodes of cervical and axillary regions. 18F-FDG PET/CT scan indicated that the spleen was markedly enlarged with FDG accumulation, with SUVmax of 5.2, and diffuse radioactivity uptake was observed in the bone marrow with an SUVmax of 5.0 (A: MIP, triangle arrows). In addition, multiple lymph nodes of cervical, supraclavicle, mediastina, axillary, abdominal, retroperitoneal, pelvic and inguinal regions were enlarged with increased radioactivity (B-D: PET, E-G: CT, and H-J: PET/CT, arrows). CT, computerized tomography; 18F-FDG, fluorodeoxyglucose; PET, positron emission tomography; SUV, standardized uptake value; MIP, maximum intensity projection.

Figure 5. A 25-year-old female presented with a mass located in the left cervical region for 1 month, fever (Tmax of 40.0°C) and joint pain for 3 weeks. The patient had history of corrective operation for deformities of the spine 10 years ago. 18F-FDG PET/CT imaging displayed that in addition to diffuse FDG uptake by the spleen and bone marrow (A: MIP, triangle arrows), multiple lymphadenopathy with abnormal FDG uptake (arrows) was observed (B-E, PET; F-I, CT; and J-M, PET/CT). The biopsy of left cervical lymph node (B, F and G; arrows) was taken and the pathology was non-specific inflammation. The biopsy of bone marrow was non-specific reactive hyperplasia of hematopoietic cells. After the therapy of CSs for 1 month, ultrasound displayed that the lymph nodes of left neck and axillary obviously shrine. 18F-FDG, fluorodeoxyglucose; PET, positron emission tomography; CT, computerized tomography; MIP, maximum intensity projection.

Figure 6. A 67-year-old female presented with fever (Tmax of 39.0°C) for 4 weeks, and anti-inflammatory therapy was invalid. 18F-FDG PET/CT imaging observed that diffuse FDG uptake by the spleen and bone marrow (A: MIP, triangle arrows), and multiple lymphadenopathy with abnormal FDG uptake in the cervical, supraclavicle, mediastinum and lung hilar regions (B and E, PET; C and F, CT; D and G, PET/CT; arrows). The pathology after the biopsy of the right supraclavicle lymph node (B-D; arrows) led to the diagnosis of non-specific inflammation. The bone marrow biopsy indicated non-specific and mild hyperplasia of hematopoietic cells, predominantly myeloid, and lymphocytes and plasma cells within normal range. During the follow-up, the lymph nodes of supraclavicle, mediastinum and lung hilar regions were significantly decreased or disappeared on chest CT images. 18F-FDG, fluorodeoxyglucose; PET, positron emission tomography; CT, computerized tomography; MIP, maximum intensity projection.

There were several limitations in the present study. i) As a retrospective study, there may have been a substantial selection bias on the basis of the physicians' decisions to request 18F-FDG PET/CT examinations; ii) Due to the small size of the population in the present study, the imaging characteristics of AOSD on 18F-FDG PET/CT could not be fully investigated; iii) the majority of patients with AOSD respond well to CS treatment, and other imaging modalities including ultrasound and local CT are commonly conducted to monitor AOSD, therefore, there is a lack of data and information concerning the follow-up PET/CT images following the appropriate therapy for AOSD.

In conclusion, due to the non-specific imaging features on 18F-FDG PET/CT examinations, 18F-FDG PET/CT scans could not directly aid in the diagnosis of AOSD. The final diagnosis of AOSD is based on clinical performance, laboratory and imaging examinations, and pathology. However, for AOSD, 18F-FDG PET/CT serves important roles in evaluating the involved extent, and guiding the biopsy of the lymph nodes, bone marrow or other tissues, which may aid in the development of novel strategies for clinical management.

Acknowledgements

The study was in part supported by the National Science Foundation for Scholars of China (grant nos. 81271608 to Dr Hongcheng Shi and 81571703 to Dr Lei Jiang), and funding sponsored by Shanghai Pujiang Program (grant no. 2015PJD006) and Zhongshan Hospital Outstanding Youth Talent Program (grant no. 2015ZSYXQN17). The abstract of the present study was presented and published at the Society of Nuclear Medicine and Molecular Imaging (SNMMI) conference held in San Diego, CA, USA in June, 2016.
