Introduction

The treatment of bone defects caused by trauma and tumors, in particular radial bone defect, is challenging in clinical practice. Approximately 800,000 bone repair surgeries with bone grafting are performed each year in the US alone. In China, >30 million bone defect cases are caused by trauma each year (1). However, the bone substitutes currently in use do not adequately combine the advantages of biocompatibility, high mechanical strength, easy degradation and low cost (2). With the developments in tissue engineering, tissue-engineered bones are being widely used as an alternative to allografts and autografts due to their low immunogenicity, absence of secondary trauma and easy availability (3,4). Different scaffolds made of a single biomaterial have respective advantages and defects in vitro and in vivo. To address this problem, a compounding technique that adjusts the proportion of each material and the way of forming the composite is currently applied (5,6). Budiraharjo et al (7) co-cultured a chitosan (CS) scaffold coated with nano-hydroxyapatite (nHA), and the stem cells and scaffold demonstrated excellent biocompatibility and osteoinductive capacity. Furthermore, Alves da Silva et al prepared a composite scaffold by polymerization of CS and silk fibroin (SF), which was then used for co-culture of bone marrow stem cells. This composite scaffold was capable of inducing chondrocyte differentiation (8).

An SF/CS composite scaffold was applied in the repair of knee joint defects in rabbits in a preliminary study (9). On the basis of good biocompatibility and appropriate degradation rates, the SF/CS/nHA composite scaffold with improved performance was prepared in the present study and used for the repair of defect in rabbit radial bone. The osteogenic capacity and mechanism were discussed in the present study using X-ray scanning and pathological observation.

Materials and methods

Materials

A total of 45 New Zealand white rabbits (age, 2 months; 24 females and 21 males; weight, 2.5±3.0 kg) were obtained from the Zunyi Medical College Animal Experiment Center (Zunyi, China). Animals were housed at 15°C and 45% humidity, with ad libitum access to standard rabbit food and water. The experiments were conducted at the Central Laboratory of Zunyi Medical College. The study design involved randomized grouping of animals and in vivo experiments. The study was approved by the Ethics Committee of Zunyi Medical College.

Preparation of SF/CS/nHA composite scaffold

The SF/CS/nHA scafford was prepared as previously described (10). SF, CS and nHA were prepared into 2% solutions and then combined in three proportions, namely 1:1:0.5, 1:1:1 and 1:1:1.5. The mixture was stirred at 55°C using a magnetic stirrer until the bubbles disappeared and the mixing was uniform. Next, the mixture was transferred to a 9-well plate using a 20 ml syringe (~50 ml/well) and frozen at −80°C for 24 h. The frozen scaffolds transformed from fluid into solid state but still contained ice, so were sealed with parafilm. A pattern of holes was made on the parafilm so that the water could be absorbed. The scaffolds were placed in a vacuum drier for 36 h. The scaffolds were then removed and soaked in a mixture of 75% methanol and 1 mol/l sodium hydroxide for 15 h. Subsequently, the scaffolds were repeatedly washed with ultra-pure water and dried again in the vacuum drier. The scaffolds were then placed for 10 h in a solution of crosslinking agents, containing 1-ethyl-3-(3-dimethylaminopropyl) carbodiimide and N-hydroxysuccinimide. After rinsing, the wet composite scaffolds were frozen at −80°C for 24 h, followed by vacuum drying for 36 h. Finally, the prepared composite scaffolds were sealed for later use (11,12).

Modeling

A total of 45 New Zealand white rabbits were fasted from food and water for 6 h before surgery. Anesthesia was induced by intravenous injection of 2.5% sodium pentobarbital via the ear margin. The rabbits were immobilized in the four limbs to prevent damage to the vessels or nerves caused by body twitching during surgery. Next, the right forelimb was exposed, the skin was disinfected conventionally with iodophor and alcohol, and incised from the midpoint of the radial bone. Dissection was performed layer by layer with caution in order not to damage the vessels or nerves. In the exposed radial bone, a defect of approximately 2 cm in length was performed using a sterilized saw blade, as previously described (13–15). After the radial bone defect was performed, rabbits were divided into three groups (n=15 each) and treated as follows: Group A, in which SF/CS/nHA composite scaffold was implanted; group B, in which SF/CS scaffold was implanted, serving as the negative control group; and group C, in which no scaffold was implanted, serving as the blank control group (16). The incision was sutured layer by layer and disinfected with iodophor following surgery, and wrapped with gauze without applying external fixation. To prevent postoperative infection, penicillin (500,000 U) and streptomycin (0.1 g) were injected intramuscularly. The rabbits were kept in separate cages subsequent to surgery.

Rough observation and X-ray scanning

The diet and mobility of rabbits were observed regularly subsequent to surgery, and the incisions were checked for reddening and infection. At 4, 6, 8 and 12 weeks after surgery, the rabbits were immobilized to obtain anteroposterior X-ray scans of the radial bone. Bony calluses and replacement of the scaffold by bone tissues were observed in X-ray scans. Rabbits were sacrificed and bone tissues were harvested at different times postoperatively (4, 6, 8 and 12 weeks after surgery, n=3 at each time point) and made into pathological specimens to evaluate the repair of bone defects, the scaffold association with the surrounding tissues and the absorption of the scaffold.

Histopathological observation

Vertical and transverse sections were prepared for a comprehensive observation. Briefly, the specimens were fixed with 4% formaldehyde, decalcified and sliced into 4-µm sections. Next, specimens were dewaxed in xylene, dehydrated through an ethanol gradient, washed with water and air dried for 24 h. Pathological observation was based on hematoxylin-eosin (HE) and toluidine blue staining. The sections were dehydrated, sealed and observed under an inverted microscope to evaluate the growth of normal bone tissues, osteogenic capacity and degradation of the scaffold. The lesions in the surrounding tissues were also observed. Lane-Sandhu histologic criteria were used (17) i) Healing: None, 0; fiber, 1; fibrocartilage, 2; bone, 3; trabecular and cortical bone, 4. ii) Callus: None, 0; small amount of callus, 1; medium callus, 2; large amount of callus, 3; fully callus, 4. iii) Bone marrow: No bone marrow, 0, bone marrow started, 1; >50% of the defect area has bone marrow, 2; complete marrow, 3; mature marrow, 4.

Statistical analysis

The results of rough observation, X-ray scan and pathological observation were analyzed using SPSS version 17.0 software (SPSS, Inc., Chicago, IL, USA). F-test was conducted to compare the mean values of multiple samples. Differences with P<0.05 were considered to be statistically significant.

Results

Postoperative conditions and observations

Rabbits were provided with food 12 h after surgery in each group. The incisions healed within 1 week without severe infection, reddening or festering. At 1 week after surgery, the rabbits in groups A and B appeared to be more active compared with those in group C, while the mobility was moderate in all groups 3 weeks later. As indicated by pathological observation, the scaffolds in groups A and B at 4 weeks after surgery were enclosed in fibrous connective tissues. The scaffolds under the periosteum presented signs of calcification and a grayish white color. Little difference was observed between groups A and B with the naked eye. At 8 weeks, the scaffold was gradually replaced by bony calluses in groups A and B. The scaffolds of group B had a light yellow color. Between weeks 12 and 16, osseointegration with a similar color and texture as that of the normal bone tissues was observed in group A. In group B, the scaffolds had a light yellow color, similar to that of the cartilage. Although the broken ends of the bone presented slight elongation at the early stage in group C, no osseointegration was observed and the defect was filled with soft tissues during the entire observational period. Fig. 1 shows the radial bone defect of each group at 16 weeks after surgery.

Figure 1. General observations of radial bone defect in rabbits treated with different scaffold materials after 16 weeks of implantation. Bone specimens are shown from rabbits with (A) SF/CS/nHA scaffold implantation (group A), (B) SF/CS implantation (group B), and (C) no treatment of the defect (group C). SF, silk fibroin; CS, chitosan; nHA, nano-hydroxyapatite.

Osteogenic capacity evaluated by X-ray scanning in each group

The results of X-ray examination conducted in group A are shown in Fig. 2. At 4 weeks after surgery, the scaffolds in the defect region presented with a grayish white high-density shadow. At 8 weeks after surgery, the calcified shadow was darkened with distinct boundary from the surrounding soft tissues. At 12 weeks, the marrow cavity was unobstructed partially between the two broken ends. Finally, at 16 weeks, no evident disparity was observed on the X-ray scans between the defect region and the normal bone tissue, while the marrow cavity was completely unobstructed.

Figure 2. X-ray observation of rabbit radial bone defect in group A, after implantation of silk fibroin/chitosan/nano-hydroxyapatite composite scaffolds.

As shown in Fig. 3, sporadic calcified shadows were observed in the scaffolds in group B at 4 weeks after surgery. These were clearly darker compared with the adjacent soft tissue shadows, though their morphology was less distinct. At 8 weeks, the calcified shadows were enhanced, although they remained lighter in color compared with normal bone tissues and were more distinct in morphology in comparison with the earlier X-ray scan. At 12 and 16 weeks after surgery, X-ray scanning revealed slightly lighter bone density shadows compared with the normal bone tissues, and the marrow cavity was partially unobstructed.

Figure 3. X-ray observation of rabbit radial bone defect in group B, after implantation of silk fibroin/chitosan composite scaffolds.

As demonstrated in Fig. 4, new bone tissues grew from the two broken ends at 4 weeks in group C, however, the length of growth was small. At 8 weeks, the calcified shadows at the two broken ends were enhanced, and the growth was insignificant. In the blank region (defect), soft tissue shadows were observed. At 12 and 16 weeks after surgery, the elongation at the two broken ends appeared to have stopped, and the calcified shadows were enhanced to the extent of resembling the normal bone tissues. As the two broken ends were closed separately, bone nonunion occurred. Groups A and B both indicated osteogenesis in early stages, but in group A, higher X-ray bone density was observed, indicating that group A had a better capacity for osteogenesis. Group C finally became bone nonunion.

Figure 4. X-ray observations of radial bone defect in group C rabbits.

Pathological observation

HE staining was performed in each group at 16 weeks. As seen from Fig. 5A, new bone tissues were observed in group A. Trabecular bones and long spindle-shaped osteocytes with deeply stained nuclei were observed under ×100 magnification. The bone plate was distinct and the central canal, while bone matrix in lamellar arrangement was detected on the outside and the osteocytes. Under higher magnification, long spindle-shaped osteocytes were observed. In group B, the scaffolds were partially replaced by bone tissues and the osteocytes were surrounded by a considerable amount of chondrocytes (Fig. 5B). However, no trabecular bones or bone plates were observed, and large amounts of chondrocytes were observed under high magnification (Fig. 5B). Furthermore, in group C, large amounts of fibrous connective tissues were detected in contrast to a few bone-like tissues. Round and deeply-stained nuclei of myofibroblasts were observed under high magnification, which were larger in size compared with the osteocytes and vacuolated adipocytes (Fig. 5C). The Lane-Sandhu histological scores of each group are listed in Table I. Group A exhibited significantly higher Lane-Sandhu scores at each time point compared with groups B and C, indicating that the scaffold in group A achieved better osteogenesis.

Figure 5. Hematoxylin-eosin staining of bone defect tissue after 16 weeks from surgery in rabbits with (A) SF/CS/nHA scaffold implantation (group A), (B) SF/CS implantation (group B), and (C) no treatment of the defect (group C). Magnification, ×100. SF, silk fibroin; CS, chitosan; nHA, nano-hydroxyapatite.

Table I. Lane-Sandhu scores in each group following scaffold implantation.

Table I.

Lane-Sandhu scores in each group following scaffold implantation.

Group	4 weeks	8 weeks	12 weeks	16 weeks
A	6.50±0.56a	8.75±0.48a	9.85±0.14a	10.54±0.13a
B	3.95±0.38	5.56±0.68	7.25±0.51	8.54±0.25
C	2.54±0.31	3.58±0.54	4.39±0.42	6.44±0.41

a P<0.05, group A vs. other groups. Values are presented as the mean ± standard deviation (n=15). Rabbits underwent SF/CS/nHA scaffold implantation (group A), SF/CS scaffold implantation, or no treatment of the defect (group C). SF, silk fibroin; CS, chitosan; nHA, nano-hydroxyapatite.

Discussion

Bone tissue engineering involves three key aspects, including the presence of signaling molecules that induce bone tissue differentiation, appropriate scaffold materials and the ideal seed cells. Among these, the use of an appropriate scaffold material is the most important aspect, and this material is required to possess good mechanical strength combined with toughness. In normal bone tissues, the tough layer of connective tissues provides support. Thus, ensuring high mechanical strength in artificial scaffolds is essential. In order to repair different types of bone defects, scaffolds that are sufficiently strong and allow remodeling are required (18). Good biocompatibility with the host is essential, which refers to the absence of immune rejection risk, inflammation or even carcinogenesis following implantation. Three-dimensional (3D) scaffolds with reticular structure and large surface area of pores are preferred since these characteristics are conducive to the regeneration of bone tissues and vessels. A large surface area facilitates the growth and adhesion of the stem cells, and results in a more uniform degradation of the scaffolds. In addition, an appropriate degradation rate of the scaffolds is crucial (19). Long-term presence of scaffolds in the host will prevent regeneration and growth of bone tissues; however, if the scaffold degrades too fast, it cannot provide the support necessary for the repair of the bone defect (20,21).

Among various materials used in tissue-engineered bones, natural polymers include collagen, CS and alginates, while artificial polymers include polylactic acid, polyphosphazenes and poly-β-hydroxybutyric acid. Furthermore, the main artificial inorganic materials used are hydroxyapatite, bioactive glass and β-tricalcium phosphate. Natural polymers are superior in biocompatibility, but poor in mechanical strength. In addition, artificial polymers contain ingredients that mimic the inorganic components of normal bone, leading to the risk of inflammation and foreign body reaction. Artificial inorganic materials are superior in plasticity and mechanical strength, but poor in hydrophilicity and controllability of degradation rates (22). Therefore, in order to combine the advantages of different materials, composite scaffolds are constructed for bone tissue engineering (23–26).

In the study by Zhu et al (27), hydroxyapatite/calcium polyphosphate/poly-L-actic acid scaffolds were prepared from the raw materials of nHA, calcium polyphosphate and polylactic acid using a solvent casting, particle filtering method and gas forming method. The scaffolds had a 3D reticular structure with an average pore size of 200–400 µm and high modulus of elasticity. The mechanical performance was enhanced in the composite scaffold compared with the scaffold composed of a single material (27). Furthermore, Xiao et al (28) adopted a co-precipitation method and prepared composite bone cement using nHA, carboxymethyl CS and sodium alginate, which was then applied to the co-culture with rabbit bone marrow stromal cells in vitro. The cells adhered to the scaffold surface and proliferated continuously at days 2, 4, 6 and 8. Under a scanning electron microscope, pseudopods were observed in the cells that were adherent to the material surface, indicating good biocompatibility with the cells in vitro. In addition, Ye et al (29) prepared 3D scaffolds from PHBV by electrospinning technology, as well as bone substitute made of β-tricalcium phosphate alone. Application of the two scaffolds for the repair of rabbit tibial bone defect indicated that the composite scaffold had a superior repair effect after 8 weeks, while the degradation rate of the composite scaffold was more conducive to the repair (29). Furthermore, Yang et al (30) used SF and HA to prepare a composite scaffold for the repair of a rabbit articular cartilage defect. The articular cartilage was then harvested and observed to have uniformly and smoothly repaired the defect. CT examination indicated smooth articular surface and normal joint space, while observation of pathological specimens showed the filling of large amounts of chondrocytes and close binding to the cartilage (30). Mature trabecular bones and reticular structure were observed with complete repair of subchondral bone, thus indicating sufficient support and biocompatibility in vivo. Therefore, as compared with scaffolds composed of a single material, composite scaffolds can achieve the desired combination of properties by changing the proportion of each ingredient and the way of compounding. Although the SF/CS scaffold prepared in a preliminary study exhibited high biocompatibility in the repair of rabbit knee joint defect, the mechanical strength required further improvement (31–33). Therefore, another ingredient, namely nHA, was introduced in the scaffold used in the present study.

The SF/CS/nHA composite scaffold constructed in the current study had a 3D reticular structure with an average pore size of 100–200 µm and excellent physical and chemical properties. In order to test its performance, a defect measuring 1.5 cm in length was induced in the middle segment of rabbit radial bones. After incising the skin and exposing the radial bone, a large segmental bone defect was made with the removal of the periosteum. Surgery was performed using the same approach and procedures in all rabbits, and the length of the defect was four times larger than the diameter of the rabbit radial shaft. The severity of the defect was far beyond the scope of self-repair. The purpose of removing the periosteum was to prevent osteogenesis from the periosteum. Within 1 week after scaffold implantation, no reddening, fever or other signs of infection were observed in all groups. The incisions healed 2 weeks later, without festering or rejection. After 16 weeks, rabbits in group A did not suffer from any systemic reactions, such as anorexia, while vomiting and death were not reported. The aforementioned results of the present study indicated good biocompatibility of the scaffold. Furthermore, X-ray scans indicated enhanced calcified shadows over time in group A, with distinct morphology and margins. The defect region did not differ from the normal bone tissue on X-ray scans conducted 16 weeks after surgery, which suggested excellent osteoinductive and osteogenic effect of the scaffold. However, the calcified shadows in group B were evidently lighter compared with group A at the same time points, indicating poor osteogenic capacity. This may be due to the introduction of nHA in the scaffold used in group A, since degradation of nHA provides calcium and phosphorus ions that are required for osteogenesis (34,35). In group C, the two broken ends of the bones were closed separately without osseointegration. Under low magnification, there were more osteoblasts in group A as compared with group B, and typical structures of bone tissues, such as trabecular bones and fibrous rings, were also observed. Under high magnification, group A had typical osteoblasts in the bone lacunae, while there were more round chondrocytes in group B. These observations provided convincing evidence that the addition of nHA enhanced the osteoinductive capacity.

In conclusion, the SF/CS/nHA composite scaffold demonstrated high biocompatibility and osteoinduction in the repair of a defect in rabbit radial bone. The degradation rate of the scaffolds was compatible with the regeneration of the bone tissues. Therefore, the SF/CS/nHA composite scaffold may qualify as a novel scaffold material, although the details of the repair mechanism currently remain unknown.
