Introduction

Central neurocytomas (CNs) are rare neuronal tumors that predominantly appear in supratentorial ventricles in young adults and account for 0.1–0.5% of all intracranial tumors worldwide (1). In 1982, Hassoun et al (2) proposed the concept of pathological diagnosis of CNs for the first time. In 1992, Nishio et al (3) first reported the extraventricular neurocytoma (EVN), an even rarer tumor than CN. In 2000, the World Health Organization (WHO) central nervous system tumor classification listed CN, which was considered as a neurogenic tumor that specially developed in the lateral ventricles or third ventricle with a good prognosis (4). However, since 2000, various tumor cases with morphological and immunohistochemical characteristics similar to those of CN but with a location outside of the ventricles have been reported (5–7). As a result, in 2007, WHO added EVN into the CNS tumor classification (8).

EVN are rarely located in the spinal cord, and only 24 cases of EVN in the spinal cord have been reported in English literatures. The present case report detailed a patient with an intramedullary CN of the thoracic spinal cord, and available literature was also summarized and reviewed.

Case report

A 50-year-old female was admitted to the Department of Neurosurgery of Peking Union Medical College Hospital (Beijing, China) in March 2014 with a history of lower back pain for 6 months and walking difficulty for half a month. At the same time, the patient also experienced zonesthesia at the epigastrium, bilateral lower extremity numbness and difficulty to place bilateral feet firmly on the ground.

According to the nervous system physical examination, the patient had bilateral lower extremity hypermyotonia. The muscle power of both lower extremities was evaluated as grade 4, according to manual muscle testing (9). The needle sensation weakened from the level of the navel to the ankle. Furthermore, the topognosis and two-point discrimination also weakened. The abdominal reflex was not observed, while hyperfunction of bilateral patellar tendon reflex existed. The patient also demonstrated Babinski and Chaddock signs that were very weak.

Magnetic resonance imaging (MRI) indicated an intramedullary irregular lesion extending from the level of T5 to T12 vertebrae, which had a length of 17 cm. The lesion showed iso/hypointense on T1-weighted images and iso/hyperintense on T2-weighted images. The margin was not very clear, making it difficult to distinguish the lesion from the normal spinal cord. Following an intravenous injection of gadolinium-diethylenetriamine pentaacetic acid (Gd-DTPA; Bayer AG, Leverkusen, Germany) at a dosage of 0.1 mmol/kg, the lesion showed intense heterogeneous enhancement of the solid part and non-enhancement of the cystic part. As demonstrated in Fig. 1, a long strip and cotton-shaped intramedullary segment showed up as hyperintense on T2-weighted images and non-enhancement was demonstrated following the administration of Gd-DTPA, which was considered as a syringomyelia caused by abnormal hydrodynamics of the cerebrospinal fluid (Fig. 1A and B).

Figure 1. MRI results. (A) Pre-operative MRI demonstrated that the lesion was iso/hyperintense on T2-weighted images. The margin was not very clear to distinguish the lesion from the normal spinal cord. The yellow arrow indicates the solid part of the tumor and the blue arrow indicates the cystic part of the tumor. (B) Following injection of gadolinium-diethylenetriamine pentaacetic acid, the lesion demonstrated intense heterogeneous enhancement of the solid part (yellow arrow) and non-enhancement of the cystic part (blue arrow). (C) Post-operative MRI indicated that the lesion was iso/hypointense on T1-weighted images. (D) T2-weighted images demonstrated that the volume of the solid part was reduced and a cyst was located in the spinal cord. MRI, magnetic resonance imaging.

The patient underwent a posterior approach laminectomy from the level of T5-T10. It was observed that the spinal dura mater was tense and so an incision was made on the dura lengthways. The spinal cord from the T5-T10 segment was obviously thickened and the pulses of the cerebrospinal fluid were not observed. An incision was made along the posterior median fissure of the spinal cord and it was revealed that the thickness of the dorsal part of the spinal cord was ~4 mm. The tumor was dark red with an abundant blood supply, with completely soft tissue characteristics. There was an unclear margin between the tumor and the normal spinal cord. Additionally, a yellow transparent liquid was observed flowing out of the cystic part of the tumor beside the solid part of the tumor when the cystic part was explored. As it was not possible for the tumor to be totally removed, 80% of the tumor was resected for the purpose of decompression. Following resection, the pulses of cerebrospinal fluid were observed prior to suturing of the incision.

Following resection, tumor tissues were immersed in 4% paraformaldehyde (PFA) for 4 h at 4°C and transferred to 70% ethanol for 2 h at 4°C. The tissues were placed in processing cassettes, dehydrated through a serial alcohol gradient (85% ethanol for 2 h, 95% ethanol for 1.5 h, 100% ethanol for 30 min at room temperature), and embedded in paraffin wax blocks. Following this, 5-µm-thick tumor tissue sections were dewaxed in xylene, rehydrated through decreasing concentrations of ethanol (95% ethanol for 2 min, 85% ethanol for 2 min, 75% ethanol for 2 min at room temperature), and washed in PBS. Subsequently, the sections were stained with hematoxylin and eosin (H&E) for 10 min at room temperature. Following staining, sections were dehydrated through increasing content ratios of ethanol (70% ethanol for 2 min, 85% ethanol for 2 min, 95% ethanol for 2 min at room temperature) and xylene for 2 min at room temperature. A light microscope was used to observe the tissue sections with magnifications of ×100 and ×400. Histopathologically, microscopic examination using H&E staining revealed that the tumor consisted of small, round uniform cells with perinuclear halos, with similar cellular structures to those observed in oligodendrogliomas. The tumor cells had finely speckled nuclei and branched blood capillaries.

For immunohistochemistry, tissues were fixed in 4% PFA overnight at 4°C and cryoprotected with 30% sucrose saturation. Tissues were sectioned to 5-µm thickness and stored at −80°C for subsequent use. The PFA-fixed tumor tissue sections were thawed for 20–30 sec and rinsed with PBS. Endogenous peroxidase activity was blocked using 6% H2O2 in 80% methanol for 10 min at room temperature. The tissue sections were then blocked with 2% normal goat serum (Abcam, Cambridge, UK) for 30 min at room temperature and incubated with a rabbit anti-human monoclonal antibody (1:250 in blocking buffer; cat. no. ab68428; Abcam, Cambridge, UK) for 2 h at room temperature, washed with PBS three times (10 min each), and incubated with a goat anti-rabbit biotinylated antibody (1:1,000 in blocking buffer; cat. no. ab7090; Abcam, Cambridge, UK) for 1 h at room temperature. The slides were washed again with PBS three times (10 min each), and immunodetection was performed using a VECTASTAIN Elite ABC system (Vector Laboratories, Inc., Burlingame, CA, USA) and with 3,3′-diaminobenzidine as a substrate. Light microscopy was used to observe the tissue sections with a magnification of ×400. The immunohistochemical examination demonstrated that the tumor cells were positive for NeuN, Oligo-2, synaptophysin (Syn) and cluster of differentiation 34 protein in blood vessels; however, the tumor cells were negative for glial fibrillary acidic protein (GFAP) and epithelial membrane antigen. Furthermore, the Ki-67 index was <1% (Fig. 2). These results, particularly those of the immunohistochemistry analysis, directed to the diagnosis of EVN according to the 2016 World Health Organization Classification of Tumors of the Central Nervous System (10).

Figure 2. H&E staining and immunohistochemistry results. (A and B) H&E staining revealed that the tumor consisted of small, round uniform cells with perinuclear halos. The tumor cells had finely speckled nuclei and branched blood capillaries [(A) magnification ×100; (B) magnification ×400]. The immunohistochemistry examination indicated that the tumor cells were positive for (C) synaptophysin, (D) cluster of differentiation 34, (E) NeuN and (F) Oligo-2. Brown coloration indicates positive staining. However, the tumor cells were negative for (G) glial fibrillary acidic protein and (H) epithelial membrane antigen. (I) The Ki-67 index was <1%. C-I, magnification ×400. H&E, hematoxylin and eosin.

The patient's postoperative recovery was satisfactory with rehabilitation training, and the patient was able to walk for ~20 min with the help of others 1 year following surgery. The patient had to rely on a wheelchair prior to surgery. Radiotherapy of 45 Gy was performed 1 month after surgery and patient follow up was conducted every 12 months for 36 months. The latest postoperative MRI indicated that the tumor had no recurrence or metastasis (Fig. 1C and D). Written informed consent was provided by the patient prior to publication of the present case report.

Discussion

EVN has similar characteristics to CN in terms of histology, pathology and immunohistochemistry; however, EVNs are not located within the ventricles (1). In addition to the cerebrum, EVNs have also been reported in the thalamus (11), the pons (12), the cerebellum (13) and the spinal cord (5). It is extremely rare for EVNs to develop in the spinal cord. Until now, a total of only 24 cases identified in the spinal cord had been reported in English literatures (5,14–30). These cases are summarized in Table I.

Table I. An overview of all reported cases of extraventricular neurocytomas located in the spinal cord.

Table I.

An overview of all reported cases of extraventricular neurocytomas located in the spinal cord.

							Immunohistochemistry
Authors, year	Age, years/sex	Location	Treatment	Follow up, months	Recurrence	Histopathology	MIB-1, %	Synaptophysin	Glial fibrillary acidic protein	(Refs.)
Coca et al, 1994	67/M	T10-11 IM	TR	30	N	Typical	NA	+	NA	(14)
Tatter et al, 1994	65/M	C2-6 IM	Bx + RT	120	N	Typical	NA	+	−	(15)
	49/M	C3-4 IM	STR + RT	72	Y	Atypical	NA	+	−
Stapleton et al, 1997	12/M	C4-T1 IM	TR	33	N	Typical	11.2	+	−	(16)
Stephan et al, 1999	46/F	T12-L1 EM	TR	12	N	Typical	1.2	NA	NA	(17)
Ashkan et al, 2000	12/M	C6-T1 IM	STR	NA	N	NA	NA	NA	NA	(18)
Baehring et al, 2005	13/M	T6-10 IM	STR	NA	N	Typical	<1	+	NA	(20)
Sharma et al, 2005	24/M	C5-T1 IM	STR	18	Y	Atypical	9–10	+	+	(5)
Makuria et al, 2007	33/M	C7-T7 IM	GTR	1	N	Atypical	30	+	+	(21)
Singh et al, 2007	8/M	T2-8 IM	STR	>3	N	Atypical	13	+	−	(22)
Gokhan et al, 2008	49/F	C3-5 IM	STR	NA	N	Typical	1	+	−	(23)
Marucci et al, 2009	51/M	T10-11 IM	TR	12	N	Typical	1	+	−	(24)
Polli et al, 2009	37/F	T12-L1 IM	STR + RT	15+12	Y	Atypical	5	+	−	(25)
	15/M	C1-T11 IM	STR	24	N	Typical	<1	+	−
	6/M	C1-7 IM	STR	23	N	Typical	<1	+	−
Agarwal et al, 2011	15/M	NA	STR + RT	6	N	NA	NA	NA	NA	(26)
	25/M	NA	STR + RT	6	N	NA	NA	NA	NA
Tsai et al, 2011	54/F	T3-5 IM&EM	GTR	6	N	NA	1	+	NA	(27)
Hanafiah et al, 2013	34/M	C6-T4 IM	STR	NA	NA	Typical	NA	+	−	(28)
Wu et al, 2014	48/F	C1-T1 IM	STR	18	N	Typical	NA	+	−	(29)
	26/M	C1-T4 IM	STR	24	N	Typical	NA	+	NA
Sun et al, 2015	26/M	C3-C7 IM	STR + RT	24	N	Typical	NA	+	+	(30)
	48/F	C5-T1 IM	STR + RT	24	N	Typical	NA	+	+
Present case	50/F	T5-T12 IM	STR + RT	36	N	Typical	<1	+	−

[i] M, male; F, female; IM, intramedullary; EM, extramedullary; RT, radiotherapy; GTR, gross total resection; STR, subtotal resection; NA, not available; Y, yes; N, no.

Of the 25 cases presented in Table I, 18 cases were male and 7 cases were female, with a sex ratio of 2.57: 1. The youngest patient was 6-years old and the oldest patient was 67-years old. However, the number of cases of spinal cord CN is too small to illustrate whether the development of the tumor is associated with age or gender. In terms of the location of the tumor, the literature revealed that these tumors are more likely to be located at the cervical or thoracic spinal cord, and the majority of the tumors are intramedullary tumors.

The clinical signs or symptoms are very similar to other intramedullary tumors and the symptoms may last for several months or years as the neurocytomas grow slowly. Furthermore, MRI characteristics are variable and sometimes it is not possible to distinguish EVNs clearly from other intramedullary tumors. The signals of primary spinal cord neurocytomas may be iso/hypointense on T1-weighted images and iso/hyperintense on T2-weighted images. The tumor may show heterogeneous enhancement following the administration of Gd-DTPA. At both ends of the tumor, syringomyelia is identified in the majority of cases (5,15,19). These characteristics are very similar to ependymomas and oligodendrogliomas, which makes it difficult to make a definite diagnosis only through the use of MRI. Therefore, it is necessary to use histopathology and immunohistochemistry features in order to make an accurate diagnosis of a spinal cord neurocytoma.

The differential diagnoses of spinal cord neurocytomas are intramedullary tumors, particularly the ependymoma and oligodendroglioma. The neurocytomas have a fine neuropil-like fibrillary matrix, while the ependymomas have a coarser glial fibrillary matrix (22). Neurocytomas are composed of small round cells, which have a slightly eosinophilic cytoplasm with clear perinuclear halos; this is very similar to oliodendrogliomas (5). Immunohistochemistry is necessary for differential diagnosis. Neurocytomas are immunopositive for Syn, which is considered the most reliable immunomarker for the diagnosis of neurocytoma (8,31). Additionally, in the present case, GFAP immunohistochemical staining was negative and the Syn immunohistochemical staining was positive, which suggested that the tumor originated from the nerve cells. These histopathology and immunohistochemistry features helped to make a definite diagnosis of spinal cord neurocytoma in the present case. Furthermore, according to the limited data from the literature review, it may be hypothesized that the recurrence rate of the tumor is more closely related to the histologic atypia and high MIB-1 labeling index. This hypothesis is similar with the view of Sharma et al (5).

Gross total resection is advised to ensure the best possible prognosis and to avoid recurrence. However, sometimes the tumor margin is not clear and it is difficult to distinguish between the normal spinal cord and the segments of the spinal cord that are involved. Therefore, subtotal resection may be a better choice to protect the normal tissue of the spinal cord. By reviewing the literature, 18 of the 25 cases (72%) underwent subtotal resection of the tumor, and 7 of the 18 (39%) that received subtotal resection also received radiotherapy following surgery.

The use of radiotherapy following subtotal resection remains to be under debate, as there is no guideline available to aid in the determination of whether or not radiotherapy should be used. Stapleton et al (16) suggested that postoperative radiotherapy should be avoided, particularly in young patients, as the tumor tends to show benign clinical behavior. However, Martin et al (19) considered that radiotherapy may delay progression and protect against recurrences following subtotal resection, thus arguing that it should be used on residual or recurrent cases with consideration of the side effects. Although chemotherapy has been demonstrated to be effective in patients with CN (32,33), it has not yet been used on spinal cord neurocytoma, and more cases are required to fully evaluate its effectiveness.

Acknowledgments

We would like to thank Dr Xiaolong Liang (Department of Pathology, Peking Union Medical College Hospital, Chinese Academy of Medical Sciences and Peking Union Medical College, Beijing, China) who provided clinical support and clinical examination.
