Characterization of solitary pulmonary nodules: Use of washout characteristics at contrast-enhanced computed tomography

Ye,Xiao-Dan; Ye,Jian-Ding; Yuan,Zheng; Dong,Sheng; Xiao,Xiang-Sheng

doi:10.3892/ol.2011.520

Characterization of solitary pulmonary nodules: Use of washout characteristics at contrast-enhanced computed tomography

Authors:
- Xiao-Dan Ye
- Jian-Ding Ye
- Zheng Yuan
- Sheng Dong
- Xiang-Sheng Xiao
View Affiliations

Affiliations: Department of Radiology, Shanghai Chest Hospital Affiliated to Shanghai Jiaotong University, Shanghai 200030, P.R. China, Department of Radiology, Fudan University Shanghai Cancer Center, Shanghai 200032, P.R. China, Department of Radiology, Affiliated Changzheng Hospital, The Second Military Medical University, Shanghai 200003, P.R. China
Published online on: December 12, 2011 https://doi.org/10.3892/ol.2011.520
Pages: 672-676

Metrics: Total Views: 0 (Spandidos Publications: | PMC Statistics: )

Metrics: Total PDF Downloads: 0 (Spandidos Publications: | PMC Statistics: )

Cited By (CrossRef): 0 citations Loading Articles...

Abstract

The purpose of this study was to determine whether computed tomographic scans and attenuation measurements on contrast material‑enhanced and non-enhanced computed tomographic scans could be used to characterize solitary pulmonary nodules and, in particular, to characterize these lesions using washout characteristics on contrast-enhanced computed tomography. A total of 63 patients (38 males, 25 females; age range, 21-80 years; mean age, 58±13.2 years) with pulmonary nodules revealed on contrast-enhanced computed tomography underwent 20-min delayed enhanced scans. The mean diameter of the pulmonary nodules was 1.8±0.6 cm (range, 0.8‑2.9). Region-of-interest measurements were obtained at non‑enhanced, dynamic enhanced and delayed enhanced computed tomography and were used to calculate a relative percentage washout as follows: 1 ‑ (Hounsfield unit measurement on delayed image/Hounsfield unit measurement on dynamic image) x 100%. There was a mean relative washout of 33% on the delayed computed tomographic scans (range, 12‑46) in benign solitary pulmonary nodules; and a mean relative washout of 7% (range, -36‑51) in malignant solitary pulmonary nodules (Mann-Whitney U test, p<0.001). Results of the receiver operating curve analysis revealed that a threshold relative washout of 14.5% had 74.3% sensitivity and 92.9% specificity for identifying malignant nodules. Calculation of the relative percentage washout on dynamic and delayed enhanced computed tomographic scans may lead to a highly specific test for solitary pulmonary nodule characterization and reduce the need for, and possibly obviate, follow-up imaging or biopsy.

View Figures

View References

1	Ost D, Fein AM and Feinsilver SH: The solitary pulmonary nodule. N Engl J Med. 348:2535–2542. 2003. View Article : Google Scholar : PubMed/NCBI
2	Shaffer K: Role of radiology for imaging and biopsy of solitary pulmonary nodule. Chest. 116:519–522. 1999. View Article : Google Scholar : PubMed/NCBI
3	Tan BB, Flaherty KR, Kazerooni EA and Iannettoni MD; American College of Chest Physicians. The solitary pulmonary nodule. Chest. 123:S89–S96. 2003. View Article : Google Scholar
4	Winer-Muram HT: The solitary pulmonary nodule. Radiology. 239:34–49. 2006. View Article : Google Scholar : PubMed/NCBI
5	MacMahon H, Austin JH, Gamsu G, Herold CJ, Jett JR, Naidich DP, Patz EF Jr and Swensen SJ; Fleischner Society. Guidelines for management of small pulmonary nodules detected on CT scans. A statement from the Fleischner Society. Radiology. 237:395–400. 2005. View Article : Google Scholar : PubMed/NCBI
6	Christensen JA, Nathan MA, Mullan BP, Hartman TE, Swensen SJ and Lowe VJ: Characterization of the solitary pulmonary nodule: 18F-FDG PET versus nodule-enhancement CT. Am J Roentgenol. 187:1361–1367. 2006. View Article : Google Scholar : PubMed/NCBI
7	Marom EM: CT of the solitary pulmonary nodule - a commentary. Am J Roentgenol. 190:1154–1155. 2008. View Article : Google Scholar : PubMed/NCBI
8	Matsuoka S, Kurihara Y, Yagihashi K, Niimi H and Nakajima Y: Peripheral solitary pulmonary nodule: CT findings in patients with pulmonary emphysema. Radiology. 235:266–273. 2005. View Article : Google Scholar : PubMed/NCBI
9	Swensen SJ, Brown LR, Colby TV and Weaver AL: Pulmonary nodules: CT evaluation of enhancement with iodinated contrast material. Radiology. 194:393–398. 1995. View Article : Google Scholar : PubMed/NCBI
10	Swensen SJ, Brown LR, Colby TV, Weaver AL and Midthun DE: Lung nodule enhancement at CT: prospective findings. Radiology. 201:447–455. 1996. View Article : Google Scholar : PubMed/NCBI
11	Yamashita K, Matsunobe S, Takahashi R, Tsuda T, Matsumoto K, Miki H, Oyanagi H and Konishi J: Small peripheral lung carcinoma evaluated with incremental dynamic CT: radiologic-pathologic correlation. Radiology. 196:401–408. 1995. View Article : Google Scholar : PubMed/NCBI
12	Yi CA, Lee KS, Kim EA, Han J, Kim H, Kwon OJ, Jeong YJ and Kim S: Solitary pulmonary nodules: dynamic enhanced multi-detector row CT study and comparison with vascular endothelial growth factor and microvessel density. Radiology. 233:191–199. 2004. View Article : Google Scholar : PubMed/NCBI
13	Zhang M and Kono M: Solitary pulmonary nodules: evaluation of blood flow patterns with dynamic CT. Radiology. 205:471–478. 1997. View Article : Google Scholar : PubMed/NCBI
14	Bernard A: Resection of pulmonary nodules using video-assisted thoracic surgery. The Thorax Group. Ann Thorac Surg. 161:202–204. 1996. View Article : Google Scholar : PubMed/NCBI
15	Keagy BA, Starek PJ, Murray GF, Battaglini JW, Lores ME and Wilcox BR: Major pulmonary resection for suspected but unconfirmed malignancy. Ann Thorac Surg. 38:314–316. 1984. View Article : Google Scholar : PubMed/NCBI
16	Jeong YJ, Lee KS, Jeong SY, Chung MJ, Shim SS, Kim H, Kwon OJ and Kim S: Solitary pulmonary nodule: characterization with combined wash-in and washout features at dynamic multi-detector row CT. Radiology. 237:675–83. 2005. View Article : Google Scholar : PubMed/NCBI
17	Pena CS, Boland GW, Hahn PF, Lee MJ and Mueller PR: Characterization of indeterminate (lipid-poor) adrenal masses: use of washout characteristics at contrast-enhanced CT. Radiology. 217:798–802. 2000. View Article : Google Scholar : PubMed/NCBI
18	Gurney JW, Lyddon DW and McKay JA: Determining the likelihood of malignancy in solitary pulmonary nodules with Bayesian analysis. Part II. Application. Radiology. 186:415–422. 1993. View Article : Google Scholar
19	Yamashita K, Matsunobe S, Tsuda T, Nemoto T, Matsumoto K, Miki H and Konishi J: Solitary pulmonary nodule: preliminary study of evaluation with incremental dynamic CT. Radiology. 194:399–405. 1995. View Article : Google Scholar : PubMed/NCBI
20	Swensen SJ, Viggiano RW, Midthun DE, Müller NL, Sherrick A, Yamashita K, Naidich DP, Patz EF, Hartman TE, Muhm JR and Weaver AL: Lung nodule enhancement at CT: multicenter study. Radiology. 214:73–80. 2000. View Article : Google Scholar : PubMed/NCBI
21	Caoili EM, Korobkin M, Francis IR, Cohan RH, Platt JF, Dunnick NR and Raghupathi KI: Adrenal masses: characterization with combined unenhanced and delayed enhanced CT. Radiology. 222:629–633. 2002. View Article : Google Scholar : PubMed/NCBI
22	Littleton JT, Durizch ML, Moeller G and Herbert DE: Pulmonary masses: contrast enhancement. Radiology. 177:861–871. 1990. View Article : Google Scholar : PubMed/NCBI
